ECMO Cannulation and Endovascular Procedures Training Platform

ECMO-B01

Designed with a transparent structure, this platform allows real-time monitoring of procedures, enabling participants to assess status, identify anomalies, and engage in immediate discussions. With integrated systemic and pulmonary circulatory systems and ECMO console compatibility, it creates an immersive environment for skill-building, teamwork, and scenario-based critical care practice.

See It in Action

Product Details

Select...

Procedures
Features
Models
Spare Parts
Specification
Download

A. Establishment of ECMO support
1. Cannulation for both access (drainage) and returning (re-infusion) cannulas.
2. Initiating ECMO together with the cannulas and ECMO circuit.
3. Hybrid ECMO configurations, such as VV-A, V-AV, VV-V, etc.
4. ECMO troubleshooting for hypovolemia, oxygenator failure, pump head or pump drive failure, cannula malpositioning, sudden introduction of air into circuits, etc.

B. Intra-aortic balloon pump (IABP) assist
1. The IABP catheter insertion.
2. Connect the IABP console.

C. Hemodialysis support
1. Insertion of a hemodialysis catheter.
2. Connect to the hemodialysis machine.

D. Impella support - Intravascular micro axial blood pumps that provide temporary MCS.

• 1:1 scale rigid male body shell.
• Integrated systemic and pulmonary circulation.
• Both ultrasound-guided and cut-down procedures are applicable.
• Adjustable heart rate, AoP, CO, and CVP.
• Panel knob control with heart rate display.
• The water reservoir capacity is 8 L.
• Multiple ultrasound-guided vascular procedures are applicable.
• Modular design leads to cost-effective training.
• Realistic appearance provides trainees with more immersive experiences.

ECMO-B01
• Applicable for the establishment of ECMO support
• Includes model base, veins (ECMO-S01*2, ECMO-S03) and arteries (ECMO-S02*2, ECMO-S04), left and right inguinal muscle pads (ECMO-S07, ECMO-S08), neck muscle pad (ECMO-S09), left and right inguinal muscle bases (ECMO-S10, ECMO-S11), neck muscle base (ECMO-S12), AC/DC converter and water filling and drainage accessories

• Femoral vein (33.5 cm, blue, replace after about 3 punctures, contains two quick connectors, already assembled) (ECMO-S01)
• Femoral artery (33.5 cm, red, replace after about 2 punctures due to higher pressure, contains two quick connectors, already assembled) (ECMO-S02)
• Internal jugular vein (33.5 cm, blue, replace after about 3 punctures, contains two quick connectors, already assembled) (ECMO-S03)
• Carotid artery (33.5 cm, red, replace after about 2 punctures due to higher pressure, contains two quick connectors, already assembled) (ECMO-S04)
• 10 m vein (blue, contains two quick connectors and a pack of zip ties, self-assembled) (ECMO-S05)
• 10 m artery (red, contains two quick connectors and a pack of zip ties, self-assembled) (ECMO-S06)
• Left inguinal muscle pad (replace after about 50 punctures) (ECMO-S07)
• Right inguinal muscle pad (replace after about 50 punctures) (ECMO-S08)
• Right neck muscle pad (replace after about 50 punctures) (ECMO-S09)
• Left inguinal muscle base (rare damage, replace when needed) (ECMO-S10)
• Right inguinal muscle base (rare damage, replace when needed) (ECMO-S11)
• Right neck muscle base (rare damage, replace when needed) (ECMO-S12)
• Vein quick connector (ECMO-S13)
• Artery quick connector (ECMO-S14)
